FL19A Stadium LED Flood Light

Name: FL19A Stadium LED Flood Light
Brand: Hangzhou Hpwinner Opto Corporation.

Power range: 300–1500 W

FL19A is a high-power LED flood light developed specifically for stadiums, football fields and professional outdoor sports venues. With a maximum output of 225,000 lm, it is designed for projects that require long-distance projection, high-mounted installation and substantial lumen packages across large playing and spectator areas.

Professional sports lighting cannot be selected by wattage alone. Field dimensions, competition level, pole positions, mounting height, horizontal and vertical illuminance, uniformity, glare limits and camera directions should be evaluated together. HPWINNER uses photometric simulation to determine the appropriate FL19A configuration, optical distribution, quantity and aiming arrangement for each venue.

FL19A provides stadium-oriented optical and CCT options. Its bracket supports adjustment through 180° in both vertical and horizontal directions, while an optional laser sight assists precise targeting during installation and commissioning. An optional stainless-steel bracket is available for demanding outdoor environments.

Features Of FL19A LED Flood Light

Die-Cast Housing & IP68 Light Engines
- Die-cast aluminum housing: Provides reliable mechanical support for high-power stadium and outdoor operation.
- IP68 LED light engines: Patented sealed light engines protect the LED source against water and dust.
- Outdoor installation: The structural design supports elevated mounting and long operating hours in professional sports venues.
Up to 1500 W and 225,000 lm
- Up to 1500W with a maximum flux output of 225,000lm
- Specialized in stadium lighting while compatible with general flood lighting.
Stadium-Oriented Optical Configuration
- Sports-lighting distributions: Optical distributions are available for stadium and professional sports applications.
- Project-based aiming: Optics and aiming directions are selected according to field dimensions, pole positions, mounting height and lighting targets.
- Horizontal and vertical illumination: The project configuration should account for the playing surface as well as visibility toward players, spectators and cameras.
- Photometric verification: Uniformity, glare, overlap and shadow zones should be evaluated before final product selection.
Precision Installation Support
- Vertical adjustment: The bracket supports adjustment through 180° in the vertical direction.
- Horizontal adjustment: The mounting structure also supports 180° horizontal adjustment for flexible stadium aiming.
- Optional laser sight: Assists precise targeting during installation and commissioning.
- Optional stainless-steel bracket: Available for harsh or corrosive outdoor environments.
